Firewall

1U

43.7 cm

26.9 cm

4.37 cm

3.63 kg

200 GB x 1

Rack-mountable

Wired

Firewall and Application Visibility and Control (AVC) throughput (1024B): 2.2 Gbps ¦ Firewall and Application Visibility and Control (AVC) and Intrusion Prevention System (IPS) throughput (1024B): 2.2 Gbps ¦ Firewall and Application Visibility and Control (AVC) throughput (450B): 800 Mbps ¦ Firewall and Application Visibility and Control (AVC) and Intrusion Prevention System (IPS) throughput (450B): 800 Mbps ¦ Transport Layer Security (TLS) throughput: 1 Gbps ¦ NGIPS throughput (1024B): 2.2 Gbps ¦ NGIPS throughput (450B): 800 Mbps ¦ IPSec VPN throughput (1024B TCP w/Fastpath): 1.2 Gbps

Maximum concurrent sessions with AVC: 400000 ¦ New connections per second with AVC: 22000

1 fan

8 x - RJ-45 ¦ 4 x - SFP (mini-GBIC) ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x serial - RJ-45 ¦ 1 x USB 3.0 - Type A

Mounting brackets

CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, Directive 2004/108/EC, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, TVCN 7317, Directive 2006/108/EC, TCVN 7189, CAN/CSA-C22.2 No. 60950-1, AS/NZS CISPR22 Class A

Internal power supply

AC 120/230 V (50/60 Hz)

Cisco Threat Defense 6.4

Limited warranty - advance hardware replacement - 90 days - response time: 10 days

0 °C

40 °C

90% (non-condensing)
