Eaton 93E - UPS - AC 208 V - 16 kW - 20000 VA - 9 Ah - RS-232 - black
Eaton 93E - UPS - AC 208 V - 16 kW - 20000 VA - 9 Ah - RS-232 - black
Ražotājs
•ERGOTRON
Ražotāja kods
•98-476
Artikuls
•1836035
Intrastat
•84734080
Pakas svars
•476 kg
Device Type
UPS - external
Colour
Black
UPS Technology
On-line
Input Voltage
AC 208 V
Frequency Provided
50/60 Hz
Input Voltage Margin
+ 20% / - 15%
Frequency Required
40 - 72 Hz
Input Connectors
Hardwire
Output Voltage
AC 208/220 V 50/60 Hz
Power Capacity
16 kW / 20000 VA
Surge Suppression
Yes
Efficiency
98%
Power Factor (PF)
0.99
Total Harmonic Distortion (THD)
5 %
Quantity
2
Technology
Lead Acid
Capacity
9 Ah
Features
Maintenance free, sealed
Remote Management Interface
RS-232
Interfaces
1 x EPO (emergency power off)
1 x management (RS-232) - 9 pin D-Sub (DB-9)
Expansion Slots
2 (total) / 2 (free) x Expansion Slot
Features
Advance Battery Management (ABM), audible alarm, LCD display, overload protection, blue LED lighting, Remote Emergency Power Off (REPO)
Compliant Standards
UL, CISPR 24, cUL, EN55022, ICES-003, IEC 61000-4-5, UL 1778, VCCI Class A ITE, EN55024, UL 60950, CISPR 22, FCC Part 15 B, IEC 62040-2, WEEE, ISO 9001:2000, ISO 14001:1996
Software Included
Eaton Intelligent Power Software Suite
Min Operating Temperature
0 °C
Max Operating Temperature
30 °C
Humidity Range Operating
5 - 95% (non-condensing)
Sound Emission
65 dBA
Width
53 cm
Depth
80 cm
Height
136 cm
Weight
476 kg
