MSI MPG A1000GL PCIE5 II 1000W PSU
MSI MPG A1000GL PCIE5 II 1000W PSU
Ražotājs
•MSI
Ražotāja kods
•MAG A1000GL PCIE5 II
Artikuls
•4392914
Intrastat
•85044090
Pakas svars
•0.169 kg
Kopā pieejams (gab.)
•30
Tuvākā piegāde
•16.03.2026
Summary
MSI MAG A1000GL PCIE5 II. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 150.500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Width: 150 mm, Depth: 150 mm, Height: 86 mm
Vendor Homepage
https://www.msi.com/Power-Supply/MAG-A1000GL-PCIE5-II
Category Code
PSU
Unit Box Height
0.235
Unit Box Length
0.295
Unit Box Width
0.13
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Combined power (+12V)
999.6 W
Combined power (+3.3V)
120 W
Combined power (+5V)
120 W
Combined power (+5Vsb)
15 W
Combined power (-12V)
3.6 W
Efficiency
90 %
Max output current (+12V)
83.3 A
Max output current (+3.3V)
22 A
Max output current (+5V)
22 A
Max output current (+5Vsb)
3 A
Max output current (-12V)
0.3 A
Number of +12V rail(s)
1
Power Factor Correction (PFC) type
Active
Power protection features
Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage
Total power
1000 W
Cabling type
Fully-Modular
EPS power connector (4+4 pin)
Yes
EPS power connector (8-pin)
No
Motherboard power cable length
600 mm
Motherboard power connector
24-pin ATX
Number of SATA power connectors
12
PCI Express power connectors (16-pin)
1
PCI Express power connectors (6+2 pin)
4
Peripheral (Molex) power cable length
450/500 mm
Peripheral (Molex) power connectors (4-pin)
1
SATA power cable length
150/500 mm
80 PLUS certification
80 PLUS Gold
ATX version
3.1
Bearing technology
FDB
Power supply unit (PSU) form factor
ATX
Purpose
PC
Cooling type
Active
Fan diameter
135 mm
Fan speed
500 - 1800 RPM
Illumination
No
Number of fans
1 fan(s)
On/off switch
Yes
Product colour
Black
Depth
150 mm
Height
86 mm
Weight
169 g
Width
150 mm
Model name
MAG A1000GL PCIE5 II
Units per Pallet
0
Units per Shipping Box
1
Unit Calculated Volume
0.009012 cubm
Unit Calculated Weight
3.3 kg
