Elo 2203LM - Medical Grade - LED monitor - 22" (21.5" viewable) - touchscreen - 1920 x 1080 Full HD (1080p) @ 60 Hz - 250 cd / m² - 1000:1 - 14 ms - HDMI, VGA - speakers - white
Elo 2203LM - Medical Grade - LED monitor - 22" (21.5" viewable) - touchscreen - 1920 x 1080 Full HD (1080p) @ 60 Hz - 250 cd / m² - 1000:1 - 14 ms - HDMI, VGA - speakers - white
Ražotājs
•ELO TOUCHSYSTEMS
Ražotāja kods
•E381048
Artikuls
•1904580
Intrastat
•85285291
Pakas svars
•7.468 kg
Ražotāja cena
•838.00 €
Kopā pieejams (gab.)
•14
Tuvākā piegāde
•23.03.2026
TFT screen, 16:9, screen size: 54.6 cm (21.5"), Projected Capacitive, multi touch (10 points), resolution: 1920x1080 pixels, VESA mount (100x100 mm), DICOM 14, response time: 14ms, brightness 225cd, viewing angle 178/178°(H/V), contrast: 1000:1, USB (type A, type B, micro-USB), VGA, HDMI, touch interface: USB, RS232, incl.: cable (USB, VGA, Audio, HDMI), power supply unit, power cable (EU, US), protection class: IP54, colour: white
Display Type
LED-backlit LCD monitor / TFT active matrix
Diagonal Size
22"
Viewable Size
21.5"
Built-in Devices
USB Hub
Aspect Ratio
16:9
Native Resolution
Full HD (1080p) 1920 x 1080 at 60 Hz
Brightness
250 cd/m²
Brightness w/touchscreen
225 cd/m²
Contrast Ratio
1000:1
Colour Support
16.7 million colours
Response Time
14 ms (tr - tf)
Vertical Refresh Rate
50 - 75 Hz
Horizontal Refresh Rate
30 - 82 kHz
Horizontal Viewing Angle
+89 / -89
Vertical Viewing Angle
+89 / -89
Screen Coating
Anti-glare
Backlight Technology
LED backlight
OSD Languages
Chinese (traditional), Chinese (simplified), English, German, French, Italian, Russian, Spanish, Japanese, Korean
Features
DICOM calibrated, TouchPro technology
Colour
White
Dimensions (WxDxH)
32.69 cm x 52.69 cm x 4.32 cm - without stand
Weight
4.8 kg
Type
Speakers - stereo
Output Power / Channel
2 Watt
Type
Touch-screen - touchscreen
Movement Detection Technology
Projected capacitive
Interfaces
HDMI ¦ VGA ¦ Audio line-out (mini-jack) ¦ USB (Type B) ¦ USB 2.0 (Type A) ¦ 4 x Micro-USB
VESA Mounting Interface
100 x 100 mm
Features
IP54 protection, IK06 impact rating
Included Accessories
2 screws, 3 tie wraps
Cables Included
1 x VGA cable ¦ 1 x HDMI cable ¦ 1 x USB cable ¦ 1 x audio cable
MTBF
50,000 hours
Compliant Standards
UL, VCCI, BSMI, cUL, CB, CCC, IC, FCC, KCC, DICOM Part 14, IP54, IEC 60601-1, ISO 14971, EAC, RCM, ANSI/AAMI ES60601-1, CoC, CAN/CSA C22.2 No. 60601-1:14, IEC 60601-1:2005 + A1:2012
Input Voltage
AC 100/240 V (50/60 Hz)
Power Consumption (Typical)
16.78 Watt
Power Consumption Sleep
0.78 Watt
Power Consumption (Off Mode)
0.36 Watt
Shipping Width
45.8 cm
Shipping Depth
63.3 cm
Shipping Height
19.8 cm
Shipping Weight
7.45 kg
Service & Support
Limited warranty - 3 years
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 80%
