Zebra ZT231 - Label printer - thermal transfer - Roll (11.4 cm) - 300 dpi - up to 203 mm / sec - USB, LAN, serial, Bluetooth, Wi-Fi(ac)
Zebra ZT231 - Label printer - thermal transfer - Roll (11.4 cm) - 300 dpi - up to 203 mm / sec - USB, LAN, serial, Bluetooth, Wi-Fi(ac)
Manufacturer
•ZEBRA
Reference
•ZT23143-T0EC00FZ
Article
•1917319
Intrastat
•84433210
Shipping weight
•10.516 kg
Manufacturer price
•1540.76 €
Label printer, thermal transfer, 12 dots/mm (300 dpi), media width (max.): 114 mm, print width (max.): 104 mm, roll diameter (max.): 203mm, speed (max.): 203 mm/s, display (touch screen, colour), USB, USB Host, RS232, Bluetooth (BLE), Ethernet, Wi-Fi (802.11ac), RAM: 256 MB, Flash: 256 MB, EPL, ZPL, ZPLII, incl.: power supply unit, power cable (EU, UK)
Printer Type
Label printer - thermal transfer - monochrome
Localisation
United Kingdom, Europe
Print Speed
Up to 203 mm/sec - B/W - 300 dpi - Roll (11.4 cm)
Built-in Devices
Tear bar, 4.3 inch colour LCD touch screen
Connectivity Technology
Wireless
Interface
USB, LAN, serial, Bluetooth, Wi-Fi(ac)
Max Resolution (B&W)
300 dpi
Language Simulation
ZPL, ZPL II, EPL2, EPL
Fonts Included
1 x scalable ¦ 7 x bitmapped
Barcodes
Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, Aztec code, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, MicroPDF417, Codabar, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, TLC39, Plessey, Code 128B, Code 128C, Code 128A, Standard 2 of 5, MSI, RSS-14
Printer Features
Zebra Programming Language (ZPL) support, Multi-level Element Energy Equalizer (E3)
RAM Installed (Max)
256 MB
Technology / Form Factor
SDRAM
Flash Memory
256 MB
Media Type
Continuous labels, die cut labels, black mark labels, notch
Max Media Size
Roll (11.4 cm)
Min Media Size (Custom)
19.4 mm
Max Media Size (Custom)
114 mm
Media Sizes
Roll (1.94 - 11.4 cm)
Max Printing Width
104 mm
Max Printing Length
3988 mm
Media Thickness Range
0.076 mm - 0.25 mm
Roll Maximum Outer Diameter
203 mm
Roll Core Diameter
76 mm, 25 mm
Media Feeders
1 x manual - 1 roll - Roll (11.4 cm)
Networking
Print server
Connections
1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 ¦ 1 x LAN
Compliant Standards
FCC Class B certified, VCCI, BSMI, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, EN55022 Class B, FCC Part 15.247, CCC, KCC, FCC Part 15.209, S Mark, cTUVus, EN 62311, RCM, EN 300 328, BIS, RSS-247, IEC 62368-1, EN 301 893, EN 55035, UKCA
Power Device
Power supply - internal
Voltage Required
AC 100-240 V
Frequency Required
50 - 60 Hz
ENERGY STAR
Yes
Service & Support
Limited warranty - 1 year
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 85% (non-condensing)
Width
24.1 cm
Depth
43.2 cm
Height
27.9 cm
Weight
9.1 kg
