Newland FM3051 Grouper - Barcode scanner - stationary - 60 frames / sec - decoded - RS-232, USB
Newland FM3051 Grouper - Barcode scanner - stationary - 60 frames / sec - decoded - RS-232, USB
Manufacturer
•NEWLAND
Reference
•NLS-FM3051-20
Article
•1912673
Intrastat
•84716070
Manufacturer price
•182.00 €
Built-in scanner, 2D, illumination: white, data formatting, connection: dual interface (RS232, USB), incl.: cable (USB), colour: black
Type
Barcode scanner - stationary
Interface Type
RS-232, USB
Scan Element Type
CMOS - white LED
Sensor Resolution
752 x 480
Frame Rate
60 frames / sec
Skew (Degrees)
40
Pitch (Degrees)
40
Print Contrast Signal (PCS)
25%
Decode Capability
Code 93, Matrix 2 of 5, Industrial 2 of 5, Code 39, ISBN, GS1 DataBar, QR code, UPC-A, UPC-E, Codabar, Code 128, Code 11, Interleaved 2 of 5, PDF417, MSI-Plessey, Data Matrix, Plessey, ISSN, ITF-14, Standard 2 of 5, EAN-8, EAN-13, RSS-14, ITF-6, RSS Expended, RSS, Chinese Sensible Code
TTL Decoding
Decoded
Connectivity Technology
Wired
OK Notification
Beeper
Features
4 kV ESD protection (direct discharge), 8 kV ESD protection (air discharge), continuous mode scanning, sense mode, 75° horizontal field of view, 50° vertical field of view, ABS housing, aluminium housing, LCD display
Interfaces
USB
Cables Included
1 x USB cable - external
Compliant Standards
FCC Part 15 B, EMC Class B, RoHS
Voltage
(50 - 60 Hz)
Power Consumption Operational
572 mW
Electric Current Required
115 mA (typical), 198 mA (maximum)
Software Included
EasySet
Width
7.87 cm
Depth
6.77 cm
Height
6.25 cm
Weight
184 g
Service & Support
Limited warranty - 5 years
Min Operating Temperature
-20 °C
Max Operating Temperature
60 °C
Humidity Range Operating
5 - 95% (non-condensing)
