Elo Desktop Touchmonitors 2201L IntelliTouch Plus - LED monitor - 22" - touchscreen - 1920 x 1080 Full HD (1080p) @ 60 Hz - 225 cd / m² - 1000:1 - 5 ms - DVI-D, VGA - speakers - black
images are for illustrative purposes only
New
Article: 369401 Intrastat: 85285291 SKU: E107766
Pricing and stock details are available to registered users only.
- Back office solutions integrating labor management and inventory analysis
- Customer assist and self-service solutions
- Interactive HD video to promote lifestyle marketing
The 2201L with Intellitouch plus multi-touch surface acoustic wave (SAW) touchscreen technology provides stable "drift-free" operation with outstanding image clarity, resolution, and light transmission - for an accurate touch response. Wide-screen format displays allow extra content on the screen and are quickly becoming preferred in corporate environments for publishing and dual window applications, and are popular in public venue environments due to a high-definition cinematic-like experience.
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Diagonal Size | 22" |
| Built-in Devices | Stereo speakers |
| Aspect Ratio | 16:9 |
| Native Resolution | Full HD (1080p) 1920 x 1080 at 60 Hz |
| Brightness | 225 cd/m² |
| Contrast Ratio | 1000:1 |
| Colour Support | 16.7 million colours |
| Response Time | 5 ms |
| Vertical Refresh Rate | 75 Hz |
| Horizontal Refresh Rate | 80 kHz |
| Horizontal Viewing Angle | 170 |
| Vertical Viewing Angle | 160 |
| Backlight Technology | LED backlight |
| Controls & Adjustments | Mute, volume, brightness, contrast, H/V position, sharpness, colour temperature, phase, clock, aspect control |
| OSD Languages | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Spanish, Japanese |
| Features | IntelliTouch Plus Surface Acoustic Wave |
| Colour | Black |
| Dimensions (WxDxH) | 55.1 cm x 19.3 cm x 39.2 cm - with stand |
| Weight | 7.5 kg |
| Type | Speakers - stereo - internal |
| Output Power / Channel | 2 Watt |
| Type | Touch-screen - touchscreen |
| Movement Detection Technology | Intellitouch SAW |
| Interfaces | DVI-D ¦ VGA ¦ Audio line-in ¦ USB ¦ Headphones |
| VESA Mounting Interface | 100 x 100 mm |
| Features | Security lock slot (cable lock sold separately) |
| Backlight Life | 30,000 hours |
| MTBF | 50,000 hour(s) |
| Compliant Standards | UL, VCCI, C-Tick, BSMI, GOST, cUL, NOM, CB, CCC, IC, FCC, RoHS, KCC, WEEE |
| Localisation | Worldwide |
| Power Supply | External |
| Input Voltage | AC 120/230 V (50/60 Hz) |
| Power Consumption (Typical) | 29 Watt |
| Service & Support | Limited warranty - 3 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 20 - 80% (non-condensing) |
